TMG-SVR72 72″ Skid Steer Vibratory Roller Attachment

Key Features

• High-Impact Compaction Output: Generates a powerful dynamic force ranging from 30 to 41 kN (over 9,200 lbf), ensuring deep-vibratory penetration and high compaction density on structural subgrades.

• Integrated Front Pushing Blade: Outfitted with a rigid structural steel pushing blade along the chassis to knock down high spots, backfill minor voids, and level materials right before the drum rolls over them.

• Oil-Bath Motor Lubrication: Features a built-in internal motor oil-bath lubrication system that continuously cools and protects core components, offering superior durability over traditional grease-point rollers during extended runtimes.

• Advanced Hydraulic Motor Protection: Equipped with a dedicated hydraulic motor protection valving set that actively prevents overheating, pressure spikes, and premature motor damage from auxiliary circuit backpressure.

• Dual Surface Drum Scrapers: Includes heavy-duty front and rear adjustable scrapers that continuously clear damp mud, sticky clay, and asphalt buildup from the 24-inch drum face to maintain a perfectly smooth rolling finish.

• Universal Skid Steer Mount: Built with a standard universal quick-attach backing plate, ensuring rapid connection and full structural compatibility with most modern skid steers and track loaders.

Technical Specifications

• Model: TMG-SVR72

• Drum Style: Smooth drum layout

• Working Drum Width: 72”

• Drum Diameter: 24”

• Overall Physical Footprint: 75” L x 39-¼” W x 25” H

• Attachment Operating Weight: 1,985 lbs (900 kg)

• Dynamic Impact Force: 30 – 41 kN (9,217 lbf maximum)

• Required Auxiliary Hydraulic Flow: 16 – 18 GPM (Standard low-flow system compatible)

• Maximum Auxiliary System Pressure: 2,320 PSI

• Mounting Interface: Universal skid steer quick mount

• Equipment Compatibility: Fits most standard skid steers, compact track loaders, and compact wheel loaders

Shipping & Delivery

• Processing Time: 2–3 business days

• Transit Time: 10–15 business days (ships directly from strategic logistics warehouses across the United States or Canada)

• Availability Note: High-demand industrial equipment; final freight dispatch is subject to low-stock warehouse parameters.

• Unloading Requirements: This product is exceptionally dense, oversized, and heavy. Mechanical unloading equipment (such as a heavy-duty forklift, a large skid steer/wheel loader with forks, or a telehandler) is strictly required at the delivery destination to safely remove the freight crate from the commercial carrier.

• Packaging Type: Heavy-duty protective metal crate shipping box

• Shipping Dimensions: 81” L x 50” W x 32” H

• Combined Shipping Weight: 2,100 lbs
